| Specifications: | |
| Model Number | DHIPD50/28RW/30-M-E |
| Image Sensor | 1/2.7" CMOS |
| Effective Pixels | 2880 (H) × 1620 (V) |
| ROM | 16 MB |
| RAM | 128 MB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual, 1/3(4)~ 1/100000s |
| Min. Illumination | 0.03 Lux@F2.0 (Color, 30 IRE)
0.003 Lux@F2.0 (B/W, 30 IRE)
0 Lux (Illuminator on) |
| Max. IR LEDs Length | Distance up to 30m |
| IR On/Off Control | Auto/ Manual |
| IR LEDs | 1 |
| Lens | |
| Lens Type | Fixed |
| Mount Type | M12 |
| Focal Length | 2.8mm |
| Max. Aperture | F2.0 |
| Field of View | H:105°, V:56°, D:125° |
| Iris Type | Fixed |
| Focus Control | 0.8 m (2.62 ft) |
| DORI Distance | Detect: 56m | Observe: 22.4m | Recognize: 11.2m | Identify: 5.6m |
| Pan / Tilt / Rotation | |
| Pan/Tilt/Rotation | Pan: 0° ~ 360° / Tilt: 0° ~ 90° / Rotation: 0° ~ 360° |
| Video | |
| Compression | H.265; H.264; H.264B; MJPEG (only supported by the sub stream) |
| Smart Codec | Smart H.265+; Smart H.264+ |
| Streaming Capability | 2 Streams |
| Resolution | 2880 × 1620 (2880 × 1620); 2688 × 1520 (2688 × 1520);
2560 × 1440 (2560 × 1440); 3M (2048 × 1536); 2304 ×
1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 ×
960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA
(640 × 480); CIF (352 × 288/352 × 240) |
| Frame Rate-Main Stream | 2880 × 1620 (1 fps–20 fps) 2688 × 1520 (1 fps–25/30 fps) |
| Frame Rate-Sub Stream | 704 × 576 (1 fps–25 fps) 704 × 480 (1 fps–30 fps)
*The values above are the max. frame rates of each
stream; for multiple streams, the values will be subjected
to the total encoding capacity. |
| Bit Rate Control | CBR/VBR |
| Bit Rate | H.264: 32 kbps–6144 kbps
H.265: 12 kbps–6144 kbps |
| Day/Night | Auto(ICR) / Color / B/W |
| BLC Mode | Yes |
| HLC Mode | Yes |
| WDR Mode | DWDR |
| White Balance | Auto; natural; street lamp; outdoor; manual; regional custom |
| Gain Control | Auto/ Manual |
| Noise Reduction | 3D DNR |
| Motion Detection | Off / On (4 Zone, Rectangle) |
| Region of Interest | Yes (4 areas) |
| Smart IR | Yes |
| Image Rotation | 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower) |
| Mirror | Yes |
| Privacy Masking | 4 Area |
| Audio | |
| Built-in MIC | Yes |
| Compression | G.711a; G.711Mu; G.726; PCM |
| Alarm | |
| Alarm Event | Network disconnection; IP conflict; illegal access; motion
detection; video tampering; audio detection; security
exception |
| Network | |
| Ethernet | RJ-45 (10/100Base-T) |
| SDK and API | Yes |
| Cyber Security | Video encryption; configuration encryption; Digest; WSSE;
account lockout; security logs; generation and importing
of X.509 certification; HTTPS; trusted boot; trusted
execution; trusted upgrade |
| Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast |
| Interoperability | ONVIF (Profile S/Profile T); CGI; P2P; Genetec; Milestone |
| Max. User Access | 6 Users |
| Storage | Local PC for instant recording |
| Web Viewer | IE, Chrome, Firefox, Safari |
| Management Software | SPRO CSS |
| Smart Phone | iPhone, iPad & Android |
| General | |
| Power Supply | 12V DC/PoE (802.3af) |
| Power Consumption | Basic: 1.7 W (12V DC); 2.5W (PoE)
Max. (ICR + H.265 + max. resolution + main stream +
DWDR + IR intensity): 3.7 W (12V DC); 4.5 W (PoE) |
| Operating Temperature | –40 °C to +60 °C (–40 °F to +140 °F) |
| Operating Humidity | ≤ 95% |
| Storage Temperature | –40 °C to +60 °C (–40 °F to +140 °F) |
| Ingress Protection | IP67 |
| Casing | Metal |
| Dimensions | 85.6 mm × Φ94.0 mm |
| Net Weight | 0.32 kg |
| Gross Weight | 0.43 kg |
