| Specifications: | |
| Model Number | DHIPQ40/ARW/60-M-I |
| Image Sensor | 1/2.9” CMOS |
| Effective Pixels | 2688(H) x 1520(V) |
| ROM | 128 MB |
| RAM | 128 MB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual, 1/3s~ 1/100000s |
| Min. Illumination | 0.008Lux@ F1.5
0.0008Lux@F1.5 (B/W, 30 IRE)
0 Lux (Illuminator on) |
| S/N Ratio | >56 dB |
| Max. IR LEDs Length | Distance up to 60m |
| IR On/Off Control | Auto/ Manual |
| IR LEDs | 4 (IR LED) |
| Lens | |
| Lens Type | Motorized vari-focal |
| Mount Type | φ14 |
| Focal Length | 2.7mm~ 13.5mm |
| Max. Aperture | F 1.5 |
| Angle of View | Horizonal: 104°–29° × Vertical: 54°–16° × Diagonal: 125°–34° |
| Iris Type | Fixed |
| Close Focus Distance | 0.8m |
| DORI Distance | Detect: 64-220m, Observe: 25.6-88m, Recognize: 12.8-44m, Identify: 6.4-22m |
| Pan / Tilt / Rotation | |
| Pan/Tilt/Rotation | Pan: 0° ~ 360° / Tilt: 0° ~ 90° / Rotation: 0° ~ 360° |
| Intelligence | |
| IVS | Intrusion, tripwire (the two functions support the classification
and accurate detection of vehicle and human) |
| Smart Search | Work Together with Smart NVR to perform refine intelligent search,
event extraction and mergin to event videos |
| Video | |
| Compression | H.265; H.264; H.264H; H.264B; MJPEG (Only supported by
the sub stream) |
| Smart Codec | Smart H265+; Smart H.264+ |
| Video Frame Rate | Main stream: 2688 x 1520@ (1-20 fps)/2560 x 1440@ (1-25/30 fps)
Sub stream: 704 x 576@(1-25 fps)/704 x 480@ (1-30 fps)
*The values above are the max. frame rates of each stream; for multiple streams,
the values will be subjected to the total encoding capacity. |
| Stream Capability | 2 streams |
| Resolution | 2688 × 1520 (2688 × 1520); 2560 × 1440 (2560 × 1440);
2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960);
720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480);
CIF (352 × 288/352 × 240) |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate | H.264: 32 kbps - 6144 kbps;
H.265: 12kbps - 6144 kbps |
| Day / Night | Auto (ICR)/ Colour / B/W |
| BLC | Yes |
| HLC | Yes |
| WDR | 120 dB |
| White Balance | Auto; natural; street lamp; outdoor; manual; regional custom |
| Gain Control | Manual; Auto |
| Noise Reduction | 3D NR |
| Motion Detection | OFF/ON ( 4 areas, rectangular ) |
| Region of Interest (RoI) | Yes ( 4 areas ) |
| Smart Illumination | Yes |
| Image Rotation | 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower) |
| Mirror | Yes |
| Privacy Masking | 4 Areas |
| Audio | |
| Built-in MIC | Yes |
| Audio Compression | G.711a; G.711Mu; G.726; PCM |
| Alarm | |
| Alarm Event | No SD card; SD card full; SD card error; Network disconnection; IP conflict; illegal access;
motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection;
defocus detection; SMD; security exception |
| Network | |
| Network Port | RJ-45 (10/100 Base-T) |
| SDK and API | Yes |
| Network Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP;
SFTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP |
| Interoperability | ONVIF (Profile S / Profile T); CGI; P2P; Milestone |
| Storage | FTP; SFTP; Micro SD card (support max. 256 GB) |
| User/Host | 6 ( Total bandwidth: 36M ) |
| Browser | IE
Chrome
Firefox |
| Management Software | SPRO CSS |
| Mobile Client | iOS; Android |
| Cyber Security | Video encryption; Configuration encryption; Digest; WSSE; Account lockout; Security logs; IP/MAC filtering;
Generation and importing of X.509 certification; syslog; HTTPS; 802.1x; Trusted boot; Trusted execution;
Trusted upgrade |
| Certification | |
| Certifications | CE-LVD:EN62368-1;
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU;
FCC:47 CFR FCC Part 15, Subpart B |
| Port | |
| Audio Input | Built-in Mic |
| Power | |
| Power Supply | 12 VDC/PoE (802.3af) |
| Power Consumption | -ZS:
Basic: 2.4 W (12VDC); 3.1 W (PoE)
Max. (H.265+intelligence on +WDR +IR on): 8.7 W (12 VDC); 10.1 W (PoE) |
| Environment | |
| Operating Temperature | –30 °C to +60 °C (–22 °F to +140 °F) |
| Operating Humidity | ≤95% |
| Storage Temperature | –40 °C to +60 °C (–40°F to +140°F) |
| Protection | IP67 |
| Structure | |
| Casing Material | Metal |
| Product Dimensions | 238.5 mm x 90.7 mm x 90.7 mm |
| Net Weight | -ZS: 0.73 kg (1.6 lb); |
| Gross Weight | -ZS: 0.99kg (2.2lb); |
